Load cell – Zemic HM2D4 – ULP Equivalent

The Zemic HM2D4 Load Cell is a robust, high-performance alloy steel load cell designed for both compression and tension applications. It is built with a nickel-plated alloy steel body, hermetically welded, and sealed to meet IP68 ingress protection standards — making it fully dust-tight and waterproof.

Thanks to its compact, spoke-type “washer” design and low installation profile, the HM2D4 is ideal for use where conventional load sensors may not fit. This makes it especially suitable for industrial and heavy-duty weighing systems such as truck scales, hopper scales, weighbridges, silos, tanks, mixing/batching plants, and automotive testing rigs.

Whether you are building a heavy-duty weighbridge, a silo-weight monitoring system, or an industrial batching scale, the HM2D4 provides a durable, accurate, and reliable measurement foundation — even in harsh, wet, or corrosive environments.

Get A Quote

Features

• Nickel-plated alloy steel construction — offers high strength, corrosion resistance, and long-term durability.

• IP68 rating — fully sealed against dust and water, suitable for harsh, outdoor, or industrial environments.

• Works in both compression and tension — versatile for different weighing or force-measurement configurations.

• Spoke-type “washer” / low-profile design — allows installation in constrained spaces or where conventional sensors may not fit.

• Wide application scope — usable for truck weighbridges, hopper scales, silos/tanks, batching plants, automotive testing, crane or hanging-scale setups, and more.

• Stable and accurate analogue output

Key Specifications

Capacity

2 ton | 5 ton | 10 ton | 20 ton | 50 ton
